54 MT55 Operation & Maintenance Manual
TRANSPORTING THE BOBCAT MINI TRACK LOADER
Loading And Unloading
AVOID SERIOUS INJURY OR DEATH
Adequately designed ramps of sufficient strength are
needed to support the weight of the machine when
loading onto a transport vehicle. Wood ramps can
break and cause personal injury.
W-2058-0807
Be sure the trailer or vehicle and ramps are of adequate
size and capacity. (See Performance on Page 112.)
Figure 67
A mini track loader with an empty bucket or no
attachment must be loaded backward onto the transport
vehicle [Figure 67].
Use a full width ramp when loading a machine with Ride-
On Platform [Figure 67]. The platform will pivot as you
move up the ramp.
NOTE: Do not load the machine on a trailer with the
Ride-On Platform installed unless you have a
full width ramp. Remove the platform if a full
with ramp is not available.
When using adjustable ramps, be sure the ramp width
and spacing adequately covers the tread width. Do not
attempt to mount ramps that are spaced too wide or too
narrow.
The rear of the trailer must be blocked or supported (Item
1) [Figure 67] when loading or unloading the mini track
loader to prevent the front end of the trailer from raising
up.
Fastening
Figure 68
Fasten the mini track loader to the transport vehicle to
prevent it from moving during sudden stops or when
going up or down slopes [Figure 68].
• Lower the bucket or attachment fully.
• Stop the engine.
• Install chains at the front and rear tie down positions
[Figure 68]. (Both sides)
• Fasten each end of the chain to the transport vehicle.
• Use load binders to tighten the chains.
REAR
FRONT
P-48425A
Alternate Front
Tie Down
