Bobcat MT55 - LUBRICATING THE MINI TRACK LOADER

89 MT55 Operation & Maintenance Manual
LUBRICATING THE MINI TRACK LOADER
Lubrication Locations
Lubricate the mini track loader as specified for the best
performance of the mini track loader. (See SERVICE
SCHEDULE on Page 61.)
Record the operating hours each time you lubricate the
Bobcat mini track loader.
Always use a good quality lithium based multi-purpose
grease. Apply lubricant until extra grease shows.
Lubricate the following locations:
Figure 118
1. Lift Cylinder Rod End (Both Sides) [Figure 118].
2. Lift Cylinder Base End (Both Sides) [Figure 118].
3. Lift Arm Pivot (Both Sides) [Figure 118].
Figure 119
4. Tilt Cylinder Base End [Figure 119].
Figure 120
5. Tilt Cylinder Rod End [Figure 120].
Figure 121
6. Bob-Tach Pivot Pin (Both Sides) (If Equipped)
[Figure 121].
7. Bob-Tach Wedge (Both Sides) (If Equipped)
[Figure 121].
P-59557C
1
2
3
P-48548
4
5
P-48550
P-48549
6
7
