OPERATING PROCEDURE (CONT’D)
Leveling The Ground Using Float
Figure 62
Move the Lift Arm / Attachment Tilt Control Lever (Item 1)
[Figure 62] all the way forward until the lever is in the
locked position to put the lift arms in the float position.
Move the lever to the right (Item 2) [Figure 62] to change
the position of the bucket cutting edge.
With the bucket tilted farther forward, there is more force
on the cutting edge and more loose material can be
moved.
Drive backward to level loose material.
Move the Lift Arm / Attachment Tilt Control Lever
backward to the NEUTRAL position to unlock from the
float position.
IMPORTANT
Never drive forward when the hydraulic control for lift
arms is in float position.
I-2005-1285
Digging And Filling A Hole
Digging
Figure 63
Move the Lift Arm / Attachment Tilt Control Lever forward
(Item 1) to put the lift arms all the way down. Move the Lift
Arm / Attachment Tilt Control Lever to the right (Item 2)
[Figure 63] until the bucket cutting edge is on the
ground. Drive forward slowly and continue to tilt the
bucket down until it enters the ground.
Move the Lift Arm / Attachment Tilt Control Lever to the
left (Item 3) a small amount to increase traction and keep
an even digging depth. Continue to drive forward until the
bucket is full. When the ground is hard, raise and lower
the cutting edge of the bucket (Items 2 and 3) [Figure 63]
while driving forward slowly.
Figure 64
Move the Lift Arm / Attachment Tilt Control Lever to the
left (Item 1) [Figure 64] to tilt the bucket backward as far
as it will go when the bucket is full.
P-81890
1
2
1
2
3
P-81889
1
P-81888
