ATTACHMENT CONTROL DEVICE (ACD) (IF EQUIPPED)
This machine may be equipped with an Attachment Control Device.
Description
The attachment electrical harness is used to control functions on various attachments that can be used with the mini track
loader.
Figure 24
The harness connector (Item 1) [Figure 24] will connect
to the electrical harness on various attachments when
the attachment is installed on the mini track loader.
Figure 25
The two switches (Item 1 and 2) [Figure 25] are used
with the electrical harness to control the movement of
different functions on the various attachments.
See the appropriate attachment Operation &
Maintenance Manual for control details.
