787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Electronic Checklist Displays
Copyright © The Boeing Company. See title page for details.
10.50.2 D615Z003-TBC
Indicates line item is complete.
Select –
• displays next incomplete normal checklist
• displays normal checklists menu page when all normal checklists are
complete
Select – overrides line item in current line item box. Item is displayed cyan.
Displayed (white) –
• when action is required, line item is incomplete
• when action is not required, line item remains white and is complete
Displayed (green) – line item is complete.
Displayed (cyan) – line item is inactive or overridden.
Highlights current incomplete line item.
Select – checklist starts over. All open loop line items become incomplete and
current line item box, cursor selection box, and cursor move to first incomplete
line item.
3
Complete Indicator
4
Normal Checklist (NORMAL) Key
5
Line Item Override (ITEM OVRD) Key
6
Checklist Line Item
7
Current Line Item Box
8
Checklist Reset (CHKL RESET) Key
February 13, 2009
