787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Landing Gear Chapter 14
Controls and Indicators Section 10
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 14.10.1
14.10 Landing Gear-Controls and Indicators
Landing Gear10 Controls and IndicatorsControls and Indicators
Landing Gear Panel
UP – the landing gear retracts.
DN – the landing gear extends.
OFF – deactivates and resets the autobrake system.
DISARM –
• disengages the autobrake system
• releases brake pressure
1, 2, 3, 4, MAX AUTO – selects the desired deceleration rate.
RTO – automatically applies maximum brake pressure when the thrust levers are
retarded to idle above 85 knots.
1
Landing Gear Lever
2
AUTOBRAKE Selector
CENTER FORWARD PANEL
3
RTO
OFF
DISARM
NORM
DOWN
LOCK
OVRD
RETRACT
270K-.82M
UP
1
2
AUTOBRAKE
ALTN
GEAR
3
4
MAX
AUTO
EXTEND
270K-.82M
4
1
2
October 31, 2007
