787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
FMC Cruise
Copyright © The Boeing Company. See title page for details.
11.42.2 D615Z003-TBC
RTE LEGS Page Modifications
When modifications are made to a RTE LEGS page, several prompt or identifying
features help the flight crew make the modifications, such as:
•ERASE
• INTC CRS TO
• INTC CRS FROM
Modified entries display in shaded white.
Add Waypoints
Waypoints can be added to the route at any point. Added waypoints are followed
by route discontinuities.
First, enter the waypoint name in the scratchpad.
Second, locate the desired line in the flight plan and push the adjacent line select
key. The scratchpad waypoint name is put into the selected line. The entered
waypoint is connected to the waypoint above it via a direct route. A route
discontinuity follows the waypoint.
For example, OED is typed into the scratchpad. Push line select key 2L to put
OED into line 2. The FMC assumes BTG direct OED. RBL and the rest of the
flight plan follow the route discontinuity.
MOD (shaded white) – replaces ACT when modification in progress.
ACT (white) – replaces MOD when ERASE selected or execute key pushed.
1
Page Title
----------
----------
---- -------------
----------------------------
561
o
83NM
791NM
241NM
ROUTE DISCONTINUITY
NEHT
3
o
16
121
o
B
90
90
538 /FL 0.
538 /FL 0.
53018 /FL 0.
53018 /FL 0.
ESARE
KAO
LBR
GT
41
RTE DATA><
/O 1GMDRTE LE S
1
4
5
2
3
DEO
June 16, 2008
