787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
Company Datalink
Copyright © The Boeing Company. See title page for details.
11.34.2 D615Z003-TBC
[Option – VHF / HF / SATCOM datalink]
Datalink
Downlinks are datalink messages transmitted to a ground station. Requests for
data and reports of FMC data are two types of downlinks. Requests are made
manually by the flight crew. Reports can be made manually or may occur
automatically.
Uplinks are messages transmitted to the airplane. Most uplinks require manual
selections by the flight crew. Some uplinks are input automatically.
MESSAGE TEXT
CLR
MSG
CDU EICASCDU
Help
Window
HILO
Chime
VHF
Data
Receiver
FMC COMM
UPLINK
XXXX
XXXX UPLINK
HF
Data
Receiver
SATCOM
Data
Receiver
FMC
Airline Operations
Datalink Data
FMF
Flight
Management
Function
CMF
Comm
Management
Function
FDCF
Flight Deck
Comm
Function
DISP
Displays
Function
787 Common Computing Resource
June 16, 2008
