787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
FMC Descent and Approach
Copyright © The Boeing Company. See title page for details.
11.43.20 D615Z003-TBC
Push – displays the THRUST LIM page.
Alternate Airport Diversions
ALTN page 1/2 data aids the flight crew in finding a suitable alternate airport. The
page displays four airports in an ETA sequence. Each airport on the list has an
XXXX ALTN page with more data. Select the XXXX ALTN page by pushing the
associated right LSK. ALTN LIST page 2/2 may contain a list of uplinked
alternate airports.
Three alternate airport uplinks can be received. ALTN LIST page 1/2 can get an
uplink for the entire page or for just the ALTN INHIB line. ALTN LIST page 2/2
can receive an uplink of alternate airport names.
Alternate Page 1/2
The first alternate page displays alternate airport data. An alternate airport can be
selected to change the flight plan destination.
The source of alternate airports can be:
• an uplink directly to this page
• automatic selection from the ALTN LIST page
• automatic selection from the navigation database
• manual entry
Alternate airports automatically selected from the alternate list or the navigation
database display in small font. When in range, all four alternates display on the
ND in cyan. The alternate airport symbols display when the ND is in the plan
mode. When in range, the selected alternate airport displays at all times on the ND
map. When in range, other alternates display on the ND when the ARPT selection
is made on the ND drop-down menu. Alternates outside the 640 NM display range
are considered offscale airports and display on the ND as directional arrows with
airport ICAO identifier and distance in NM.
7
Thrust Limit (THRUST LIM)
August 14, 2009
