787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Hydraulics -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 13.10.3
Status Display
Quantity (QTY) –
• displays system reservoir quantity as a percentage of the normal service
level (1.00 is the normal service level)
• LO (amber) – displayed when the reservoir quantity is low
• OF (white) – displayed when the reservoir is over–full (inhibited in flight)
• RF (white) – displayed when the reservoir requires refilling (inhibited in
flight).
Pressure (PRESS) – displays hydraulic system pressure in pounds per square inch.
1
Hydraulic Display
PRESS
LO
LRC
QTY
0.72
RF
5010
0.40
4850
1.25
OF
4650
HYDRAULIC
MULTIFUNCTION DISPLAY
1
June 16, 2008
