787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Electronic Checklist Description
Copyright © The Boeing Company. See title page for details.
10.60.6 D615Z003-TBC
Timers are activated by completing the step just prior to the line item associated
with the timer. Timers run in the background. This allows the flight crew to leave
the checklist to accomplish other tasks and then return to the checklist. An
accurate countdown time is displayed. Timers initially appear in white. When the
time elapses, the timer displays 00:00 and the color changes to amber. When the
current line item box moves to the next incomplete item, the expired timer is
removed from display.
Checklist Menu Operation
An alternate means of operating the checklist is through the use of menus. The
normal, resets, and non–normal menus can be selected by the keys at the top of the
checklist page, using the cursor control device.
An EXIT MENU key is located in the lower right corner of all menu displays. This
exits the menu page to allow access to the normal and non–normal checklist keys.
Normal Menu
Normal checklists are arranged in the menu in sequence. Selecting the NORMAL
menu key or the checklist display switch results in the display of the next
incomplete normal checklist in sequence.
Non–Normal Menu
Non–normal menu selections are arranged by airplane system. Sub-menus are
used to select the appropriate checklist.
Resets Menu
Selecting the RESETS menu key displays miscellaneous information (such as
checklist database part number and revision information) and the following
selectable resets:
• RESET NORMAL
• RESET NON–NORMAL
• RESET ALL
This provides a way to reset multiple checklists (Refer to Checklist Resets
in
Chapter 10, Section 60, for additional information.).
February 13, 2009
