Preflight Procedure – Captain
The captain normally does this procedure. The first officer may do this
procedure if needed.
EFIS control panel .............................................................................. Set
MINIMUMS reference selector – RADIO or BARO
MINIMUMS selector – Set decision height or altitude reference
FLIGHT PATH VECTOR switch – As needed
METERS switch – As needed
BAROMETRIC reference selector – IN or HPA
BAROMETRIC selector – Set local altimeter setting
ND mode selector – Select MAP
ND mode select switch – Push
MENU – Select
Map selections – As needed
ND CENTER switch – As needed
ND range selector – 0.5, 1, 2 or 5
Displays airport map.
CAUTION: Do not use the Airport Map application as a
primary navigation reference. The Airport Map
application is designed to aid flight crew
positional awareness only.
ND WXR switch – Off
Verify that the weather radar indications are not shown on the
ND or PFD mini-map.
ND TFC and TERR switches – As needed
Display select panel............................................................................. Set
EICAS TRANSFER switch – As needed
Select EICAS to the desired side.
