787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Electronic Flight Bag - System
Operation
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.80.37
Video Surveillance (Typical)
[Option – Video surveillance]
The video surveillance application on the EFB provides immediate real-time
video surveillance of the area outside the flight deck entrance. If installed,
expanded video surveillance is available for other parts of the aircraft. To start the
application, select VIDEO from the EFB Main Menu page. The Video
Surveillance page displays the default view set by the administrator when the
application is started.
Selecting an Image
The Video Surveillance page displays four video images; the largest is the primary
image and the three smaller are the thumbnail images. Each thumbnail view is
from a different area of the aircraft. The primary image is an enlarged duplicate
view of the currently selected thumbnail image. Both the current thumbnail and
the primary image are bordered in green when selected and operating.
To select a different thumbnail to display in the primary image area, touch the
thumbnail view on the screen. The cursor device may also be used to highlight and
select the thumbnail view.
Manipulating the Display
To freeze the current primary image select the FREEZE soft key. Selecting
FREEZE does the following:
• stops the video and displays a still image
• image border changes from green to cyan to help indicate a frozen image
• toggles the soft key to UNFREEZE
Select UNFREEZE to return to live video.
To manipulate the display further, select the SHOW MENU soft key on the Video
Surveillance page. Several more soft key options become available for changing
the display. These additional options are:
• BRIGHT + – increases the brightness of the image
• BRIGHT - – decreases the brightness of the image
• HIDE MENU – returns to the thumbnail Video Surveillance page
• DEFAULT – returns all settings to their defaults
• CONTRAST + – increases the contrast of the image
• CONTRAST - – decreases the contrast of the image
• MAINTENANCE – displays the Maintenance page for maintenance use
June 16, 2008
