787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
11.10.16 D615Z003-TBC
Push –
• toggles the selection of the left or right ATC transponder / TCAS system
• the selected system is highlighted in large green font
The left system is the default selection.
Note: If a transponder becomes inoperative, the TCP senses the fault and
automatically switch operation to the other side. The change in the XPDR
SYS field (i.e. from L to R) may be the only indication the flight crew
receives that an autoswitch has occurred. The flight crew is still be able to
manually select an inoperative side.
(Refer to Traffic Alert and Collision Avoidance System (TCAS)
in Chapter 15,
Section 10, for additional information.)
(Refer to Traffic Alert and Collision Avoidance System (TCAS)
in Chapter 15,
Section 10, for additional information.)
3
Transponder System (XPDR SYS)
4
XXXX TCAS Display
5
XXXX TCAS Altitude (ALT)
February 13, 2009
