Flight Management, Navigation -
FMC Cruise
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 11.42.47
Active waypoint displays in magenta.
Can not be modified.
Waypoint after TO waypoint displays in white.
Can not be modified
Any waypoint or airport in navigation database can be entered. The line titles are:
• DEST – performance predictions to destination. Default display
• DIR TO FIX – when entered waypoint is not in flight plan. Data is based
on flying present position direct to the waypoint
• EN ROUTE WPT – when entered waypoint is in flight plan. Line data are
based on flying the flight plan route to the waypoint
• MOD – a modification has been made on another page. Performance
predictions include modification
Remove entries with DELETE key or change all CDU displays to a different page.
The FMC active command speed displays in magenta.
The active speed mode is the same as on the performance page, unless changed by
the MCP or a limit. The speed modes are:
• CO SPD – engine out operations at airline specified engine out company
speed
• ECON SPD – economy speed
• EO SPD – engine out speed
• LIM SPD – speed is limited by VMO, MMO, flap limit, or buffet limit
• LRC SPD – long range cruise speed
• MCP SPD – MCP speed entered on the MCP IAS/MACH indicator
• RTA SPD – RTA speed is active
• SEL SPD – selected speed manually entered on the CDU
• VREF +80 – for engine out operations during takeoff
Push – displays the POS REPORT page.
Estimated time of arrival at waypoint or destination.
Distance to go to waypoint or destination.
1
TO
2
NEXT
3
Destination (DEST)
4
Selected Speed (SEL SPD)
5
Position Report (POS REPORT)
6
ETA
7
Distance To Go (DTG)
