787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
FMC Descent and Approach
Copyright © The Boeing Company. See title page for details.
11.43.12 D615Z003-TBC
NONE displays when there are no STARS in the database.
Push -
• selects STAR or PROF DES for entry into the route, <SEL> displays
• all other arrival procedures no longer display and transitions for the
selected procedure display
• deletes a previously selected procedure
• displays ERASE prompt
Displays list of transitions for the selected arrival procedure.
Push -
• selects transition for entry into the route
• all other transitions no longer display
Push – displays the DEP/ARR INDEX page.
Displays the active route number (RTE 1 or RTE 2).
Displays the destination airport approaches.
ICAO eight character approach names are supported. Example: RNVZ 08R.
Selection and execution of an ILS approach autotunes the ILS receivers and
displays the course. Selection and execution of a back course (BAC) approach
autotunes the ILS and displays the front course.
Push -
• selects approach for entry into the route; <SEL> displays; TRANS
replaces RUNWAYS
• displays profile descents for the selected approach; deletes all other
approaches and runways
• displays INTC prompt for the selected approach
• displays ERASE prompt
Displays whenever a localizer based approach (ILS, IGS, LOC, BAC, LDA, SDF)
is in the currently displayed, selected or active flight plan.
Provides a means of using FMC computed glidepath when ILS glideslope is not
available.
Push – toggles glideslope on or off.
3
STAR Transitions (TRANS)
4
INDEX
5
Route 1 (RTE 1)
6
APPROACHES
7
Glideslope (G/S)
August 14, 2009
