787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
FMC Descent and Approach
Copyright © The Boeing Company. See title page for details.
11.43.16 D615Z003-TBC
Displays a list of runways for destination airport.
Push –
• selects runway for entry into the route
• deletes previously selected approach
• allows selection of VFR approach or entry of RWY EXT data
• deletes all other runways and approaches
• displays approach intercept fix for selected runway
Push – displays the active route page 2/X.
Push – makes a transition waypoint, FAXXX at 8 NM and 2000 feet above the
runway.
Creates a descent constraint 50 feet above runway threshold.
Displays when a VFR approach is in navigation database for selected runway.
1
RUNWAYS
2
ROUTE
3
VFR Approach (VFR APPR)
HWM
HWM
23
SYAWNUR
TXEYWR
MN0.6
SLAVIRRAK
SLAVIRRAK
1/1
1/1
TXEYWR
MN-.--
>RPPARFV
R
SRATS
S>LE<ENON
1ETR
ETUOR<XEDNI
------------- -------------------------
>
6
October 31, 2007
