787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
FMC Descent and Approach
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 11.43.31
Normally displays dashes.
Valid entry is X/XXX, XX/XXX, or /XXX. Example: NW/330.
Entry changes INBD CRS/DIR to agree.
Displays inbound course and turn direction.
Valid entry is XXX (inbound course), XXX/X (inbound course/turn direction), /X
or X (turn direction).
Entry changes QUAD/RADIAL to agree.
Displays magenta when the holding fix is the active waypoint.
Displays T if mag/true reference is in TRUE.
Displays 1.0 MIN (minute) at or below 14,000 feet.
Displays 1.5 MIN above 14,000 feet.
Displays dashes when an entry made on LEG DIST line.
Valid entry is X, X.X, or .X.
When climbing/descending through 14,000 feet with VNAV active and the
SPD/TGT ALT at 1R displays in large font, the FMC adjusts the leg time (1.0 MIN
at or below 14,000 feet; 1.5 MIN above 14,000 feet).
Normally displays dashes. Allows entry of leg distance for hold.
Entry displays dashes on LEG TIME line.
Valid entry is X, XX, X.X or XX.X, where X is any integer.
Erases all FMC modifications.
Dashes display or fix speed/altitude constraint from the RTE LEGS page.
Manual entries are in large font.
During cruise, entry of a target altitude lower than CRZ ALT modifies the
DESCENT page and displays a T/D. After T/D, the DESCENT page remains
active unless a new cruise altitude is entered.
Speed or altitude may be entered.
With no EFC TIME entry, displays time the airplane will next pass the holding fix.
4
Quadrant/Radial (QUAD/RADIAL)
5
Inbound Course/Direction (INBD CRS/DIR)
6
Leg Time (LEG TIME)
7
Leg Distance (LEG DIST)
8
ERASE
9
Speed/Target Altitude (SPD/TGT ALT)
10
FIX ETA
August 14, 2009
