787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Warning Systems -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
15.10.2 D615Z003-TBC
Displayed (amber) –
• lowest priority alert messages; indented one space
• amber alert messages can be canceled or recalled by pushing the
CANC/RCL switch
Displayed (white) –
• preceded with white dot
• COMM low messages indented one space
• cannot be canceled by pushing the CANC/RCL switch
Displayed (white) –
• reminder of selected state of controls or systems
• cannot be canceled by pushing the CANC/RCL switch
• EICAS alert messages have display priority over memo messages; some or
all memo messages not displayed on current EICAS message page if
insufficient message lines are available below alert messages
Displayed (white) –
• more than one page of alert or memo messages exists
• indicates number of page selected
Displayed (cyan) –
• new status message exists
• no longer displayed when status display selected
[Option – 30 min inhibit]
• inhibited from beginning of first engine start until 30 minutes after lift-off
Displayed (white) –
• when CANC/RCL switch pushed
• remains displayed for one second after switch released
4
Advisory Messages
5
Communication Messages
6
Memo Messages
7
Page (PG) Number
8
STATUS Cue
9
RECALL Indication
October 31, 2007
