787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Warning Systems -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
15.10.24 D615Z003-TBC
TERR RANGE DISAGREE (amber) –
• terrain display enabled, and
• terrain output range disagrees with range selected by EFIS control panel
MAP/TERR RANGE DISAGREE (amber) –
• terrain display enabled, and
• terrain output range disagrees with range selected by EFIS control panel,
and
• map display output range disagrees with range selected by EFIS control
panel
Refer to Ground Proximity Warning System (GPWS)
, Ch. 15, Sec. 20, for
additional information.
3
Terrain Range Status Annunciation
August 14, 2009
