787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Warning Systems -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
15.10.26 D615Z003-TBC
Symbol, radials, and weather radar returns displayed automatically when:
• PWS alert occurs, and
• WXR is not selected on either ND, and
• respective ND is in MAP or MAP CTR mode
When terrain display is selected and PWS alert occurs, weather radar display
replaces terrain display.
WINDSHEAR (amber) – PWS caution alert is occurring.
WINDSHEAR (red) – PWS warning alert is occurring.
Displayed in all navigation display modes.
3
WINDSHEAR Annunciation
August 14, 2009
