Boeing 787-8 - Page 256

787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Performance Inflight
General
787-8/
FAA
Category A Brakes
Copyright © The Boeing Company. See title page for details.
PI.10.22 D615Z003-TBC
Flight With Unreliable Airspeed / Turbulent Air Penetration
Altitude and/or vertical speed indications may also be unreliable.
Holding
Flaps Up, Set Thrust for Level Flight
Terminal Area (5000 FT)
Set Thrust for Level Flight
Final Approach (1500 FT)
Gear Down, Set Thrust for 3° Glideslope
PRESSURE ALTITUDE (FT)
WEIGHT (1000 LB)
300 350 400 450 500
10000
PITCH ATT 4.0 4.0 4.5 4.0 4.0
TPR 24.6 27.3 29.9 32.5 35.1
KIAS 206 217 226 240 259
5000
PITCH ATT 4.0 4.0 4.5 4.5 4.5
TPR 21.7 24.1 26.3 28.6 30.9
KIAS 206 216 225 235 249
FLAP POSITION
(VREF + INCREMENT)
WEIGHT (1000 LB)
300 350 400 450 500
FLAPS UP PITCH ATT 4.5 5.0 5.0 5.5 6.0
GEAR UP TPR 21.4 23.7 26 28.4 30.8
VREF30+80 KIAS 206 217 226 235 241
FLAPS 1 PITCH ATT 6.0 6.5 6.5 7.0 7.5
GEAR UP TPR 22.5 25.1 27.6 30.2 32.8
VREF30+60 KIAS 186 197 206 215 222
FLAPS 5 PITCH ATT 3.5 3.5 4.0 4.0 4.5
GEAR UP TPR 23.1 25.9 28.6 31.3 34.1
VREF30+40 KIAS 166 177 186 195 202
FLAPS 15 PITCH ATT 4.5 5.0 5.0 5.0 5.5
GEAR UP TPR 24.2 27.3 30.3 33.4 36.6
VREF30+20 KIAS 146 157 166 175 182
FLAPS 20 PITCH ATT 3.0 3.5 3.5 3.5 4.0
GEAR DOWN TPR 34.6 39.1 43.6 48.2 52.5
VREF30+20 KIAS 146 157 166 175 182
FLAP POSITION
(VREF + INCREMENT)
WEIGHT (1000 LB)
300 350 400 450 500
FLAPS 20
VREF20+10
PITCH ATT 1.5 1.5 1.5 1.5 1.5
TPR 15.8 17.4 19.0 20.6 22.1
KIAS 138 149 158 168 177
FLAPS 25
VREF25+10
PITCH ATT 1.5 1.5 2.0 2.0 2.0
TPR 17.1 18.9 20.6 22.4 24.1
KIAS 137 148 157 166 175
FLAPS 30
VREF30+10
PITCH ATT 1.5 1.5 2.0 2.0 2.0
TPR 18.9 21.0 23.0 25.1 27.1
KIAS 135 144 154 163 171
February 15, 2010
