787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Performance Inflight
Advisory Information
787-8/
FAA
Category A Brakes
Copyright © The Boeing Company. See title page for details.
PI.12.20 D615Z003-TBC
ADVISORY INFORMATION
Advisory Information
Recommended Brake Cooling Schedule
Event Adjusted Brake Energy (Millions of Foot Pounds)
No Reverse Thrust
2 Engine Reverse Thrust
Cooling Time (Minutes)
REFERENCE BRAKE ENERGY PER BRAKE (MILLIONS OF FOOT POUNDS)
EVENT 102030405060708090100110120130
RTO MAX MAN 102030405060708090100110120130
LANDING
MAX MAN 6.7 15.9 25.3 34.9 44.6 54.5 64.6 74.7 85.0 95.5 105.9 116.3 126.8
MAX AUTO 6.1 14.6 23.1 31.8 40.8 50.0 59.5 69.4 79.8 90.6 101.6 112.6 123.7
AUTOBRAKE 4 5.6 13.6 21.5 29.5 37.6 46.0 54.8 63.9 73.5 83.7 94.0 104.4 114.7
AUTOBRAKE 3 5.4 12.9 20.3 27.7 35.1 42.8 50.8 59.1 68.0 77.6 87.3 97.0 106.7
AUTOBRAKE 2 5.0 12.1 18.9 25.7 32.5 39.4 46.6 54.2 62.3 71.1 80.1 89.0 98.0
AUTOBRAKE 1 4.2 10.6 16.7 22.8 28.9 35.1 41.5 48.3 55.5 63.3 71.2 79.2 87.1
REFERENCE BRAKE ENERGY PER BRAKE (MILLIONS OF FOOT POUNDS)
EVENT 102030405060708090100110120130
RTO MAX MAN 102030405060708090100110120130
LANDING
MAX MAN 6.2 14.5 23.0 31.8 40.8 49.8 58.9 68.1 77.3 86.3 95.4 104.4 113.5
MAX AUTO 4.1 10.2 16.6 23.4 30.6 38.2 46.3 54.9 64.0 73.6 83.4 93.2 103.0
AUTOBRAKE 4 2.2 6.5 11.1 16.2 21.7 27.7 34.2 41.3 49.1 57.5 66.2 74.8 83.4
AUTOBRAKE 3 1.2 4.3 7.5 11.2 15.2 19.6 24.7 30.4 36.8 44.1 51.6 59.0 66.5
AUTOBRAKE 2 0.6 2.9 5.2 7.7 10.5 13.7 17.4 21.7 26.7 32.5 38.6 44.7 50.8
AUTOBRAKE 1 0.1 1.8 3.5 5.3 7.2 9.3 11.8 14.7 18.2 22.2 26.5 30.7 34.9
EVENT ADJUSTED BRAKE ENERGY (MILLIONS OF FOOT POUNDS)
16 & BELOW1718222630343536 TO 4445 & ABOVE
GEAR DOWN
INFLIGHT
NO SPECIAL
PROCEDURE
REQUIRED
1235677
CAUTION
FUSE PLUG
MELT ZONE
GROUND 12 18 35 49 60 72 73
BRAKE
TEMPERATURE
INDICATION
UP TO 2.4 2.4 2.6 3.1 3.7 4.3 4.8 4.9 5.0 TO 6.2 6.3 & ABOVE
Observe maximum quick turnaround limit.
Table shows energy per brake added by a single stop with all brakes operating. Energy is assumed to be
equally distributed among the operating brakes. Total energy is the sum of residual energy plus energy
added.
Add 1.0 million foot pounds for each taxi mile.
For one brake deactivated, increase brake energy by 13 percent.
For two brakes deactivated, increase brake energy by 25 percent.
When in caution zone, wheel fuse plugs may melt. Delay takeoff and inspect after one hour. If overheat occurs
after takeoff, extend gear soon for at least 8 minutes.
When in fuse plug melt zone, clear runway immediately. Unless required, do not set parking brake. Do not
approach gear or attempt taxi for one hour. Tire, wheel and brake replacement may be required. If overheat
occurs after takeoff, extend gear soon for at least 12 minutes.
Brake temperature indication on Multifunction Display may be used 10 to 15 minutes after airplane has come
to a complete stop, or inflight with gear retracted, to determine recommended cooling schedule.
February 15, 2010
