Boeing 787-8 - Page 309

787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Performance Inflight Chapter PI
Gear Down Section 16
787-8/
FAA
Category A Brakes
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC PI.16.1
PI.16 Performance Inflight-Gear Down
GEAR DOWN
Gear Down
220 KIAS Max Climb TPR
Long Range Cruise Altitude Capability
Max Climb Thrust, 300 ft/min residual rate of climb
TAT
(°C)
PRESSURE ALTITUDE (1000 FT)
0 5 10 12 14 16 18 20 22 24 26 28 30 32 34
55 51.4 52.4 55.9 56.2 53.3 50.2 62.1 63.3 64.0 65.4 67.0 68.1 69.2 71.8 74.5
50 54.6 54.7 55.9 56.2 57.3 54.1 62.1 63.3 64.0 65.4 67.0 68.1 69.2 71.8 74.5
45 58.3 58.1 55.9 56.2 58.3 58.0 62.1 63.3 64.0 65.4 67.0 68.1 69.2 71.8 74.5
40 61.7 62.0 59.8 57.6 58.3 60.2 62.1 63.3 64.0 65.4 67.0 68.1 69.2 71.8 74.5
35 65.1 66.1 63.7 62.0 61.1 60.3 62.1 63.3 64.0 65.4 67.0 68.1 69.2 71.8 74.5
30 68.0 69.8 68.1 66.3 65.3 64.5 63.8 63.3 64.0 65.4 67.0 68.1 69.2 71.8 74.5
25 68.2 74.1 72.5 70.5 69.6 68.7 68.1 66.6 64.6 65.4 67.0 68.1 69.2 71.8 74.5
20 68.4 76.4 76.3 74.6 73.9 73.1 72.4 70.9 68.9 68.0 67.0 68.1 69.2 71.8 74.5
15 68.6 76.6 80.7 78.6 78.1 77.6 76.9 75.3 73.1 72.4 71.6 70.1 69.2 71.8 74.5
10 68.8 76.8 81.7 82.7 82.2 81.7 81.3 79.8 77.4 77.0 76.4 74.8 73.3 73.4 74.5
5 68.9 77.0 81.9 82.9 84.5 85.8 85.6 84.2 81.7 81.7 81.3 79.6 78.0 78.0 78.3
0 69.1 77.2 82.2 83.1 84.7 86.8 89.5 88.8 86.2 86.2 86.3 84.6 83.0 82.6 82.8
-5 69.3 77.4 82.4 83.3 85.0 87.1 89.7 91.3 91.0 90.7 90.9 89.6 88.1 87.5 87.3
-10 69.5 77.6 82.6 83.5 85.2 87.3 89.9 91.6 91.9 94.2 95.2 94.0 92.7 92.4 92.0
-15 69.7 77.8 82.8 83.7 85.4 87.5 90.1 91.8 92.1 94.5 97.0 98.1 97.0 96.7 96.4
-20 69.8 78.0 83.0 84.0 85.6 87.8 90.4 92.0 92.3 94.7 97.2 98.3 99.4 101.1 100.9
WEIGHT
(1000 LB)
PRESSURE ALTITUDE (FT)
ISA + 10°C
& BELOW
ISA + 15°C ISA + 20°C
500 17800 16000 13900
480 18900 17200 15300
460 19900 18400 16500
440 20900 19500 17900
420 21900 20600 19100
400 23100 21600 20300
380 24400 22900 21300
360 25800 24400 22600
340 27000 26000 24300
320 28200 27200 26100
300 29400 28500 27400
280 30800 29800 28800
260 32300 31300 30200
240 33800 32800 31800
220 35300 34500 33500
February 15, 2010
Gear Down
