787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 1.30.19
Allows viewing of persons in the immediate area outside the flight deck door.
Allows the flight crew to manually trigger the decompression latch which opens
the decompression panel to aid in egress should the door become jammed.
Flight Deck Access Keypad
5
Viewing Port
6
Decompression Latch Instruction Placard
7
Decompression Latch Override
21
34
5
ENT
PASSENGER SIDE DOOR POST
1
2
February 15, 2010
