787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Communications -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
5.10.18 D615Z003-TBC
Displays –
• a directory of dial codes
• a dial code and label of predefined station or station groups for incoming
or outgoing call
• INVALID ENTRY message when incorrect dial code is entered
• PUSH RESET when handset is off hook and not being used for more than
30 seconds
Push –
• connects the handset microphone to the selected PA area
• only used in the PA mode
Push – selecting a code calls the respective station or PA area.
Note: Dial codes entered using the handset are not displayed on the TCP cabin
interphone pages.
Push – cancels a call or incorrectly selected code.
Push – moves up and highlights dial code from a list of predetermined crew
station(s) and PA areas.
Push – initiates a call to the selected crew station(s) or PA area dial code.
Push – moves down and highlights dial code from a list of predetermined crew
station(s) and PA areas.
Push – releases printer cover and handset cradle for access to printer paper door.
1
Handset Display
2
Handset PA Push-To-Talk Switch
3
Handset Numeric Keys
4
Handset Reset Switch
5
Handset Dial Code Step Up Switch
6
Handset Dial Code Select Switch
7
Handset Dial Code Step Down Switch
8
Printer Cover Release Lever
June 16, 2008
