787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Communications -
MFD Communications Functions
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 5.40.41
Displays the last sequenced FMC waypoint. Displays all asterisks (*) when no
FMC data is available.
Latitude and longitude are displayed in the same order as the FMC position report
page. Degree and minute values precede the compass letter, just as the crew uses
in a voice report.
Displays current altitude.
Displays the next FMC waypoint. Accepts any valid FMC waypoint entry.
Requires manual entry for ATC reporting position which is not a route waypoint.
Displays the next FMC waypoint following EST waypoint. Accepts any valid
FMC waypoint entry. Requires manual entry for ATC reporting position which is
not a route waypoint.
Displays current air temperature. Displays all asterisks (*) when no FMC data is
available.
Displays the current FMC speed. Accepts valid speed entry. Displays all asterisks
(*) when no FMC data is available.
Displays FMC calculated fuel remaining at the POS waypoint. Displays all
asterisks (*) when no FMC data is available.
Select LIGHT, MODERATE or SEVERE to report current turbulence condition.
Up to two lines of free text can be included.
Displays actual time of arrival at the last sequenced FMC waypoint. Displays all
asterisks (*) when no FMC data is available.
Displays estimated time of arrival for the next FMC waypoint. Accepts valid time
entry.
Displays current wind bearing and speed. Displays all asterisks (*) when no FMC
data is available.
2
POS
3
ALTITUDE
4
EST
5
NEXT
6
TEMP
7
SPEED
8
POS FUEL
9
TURBULANCE
10
FREE TEXT
11
ATA
12
ETA
13
WIND
October 31, 2007
