Boeing 787-8 - Page 647

787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Communications -
MFD Communications Functions
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 5.40.65
HF Manager
If the DEFAULT RADIO LEFT is selected, the left HF radio becomes the default
radio. If the DEFAULT RADIO RIGHT is selected, the right HF radio becomes
the default radio.
If the DEFAULT RADIO MODE: DATA is selected, the default HF radio is set to
data mode. If the DEFAULT RADIO MODE: VOICE is selected, the default HF
radio is set to voice mode.
ATC
COMPANY
REVIEW
RETURN
EXIT
LINK
0052z HF
DEFAULT RADIO
LEFT
DEFAULT RADIO MODE
DATA
DEFAULT RADIO
RIGHT
DEFAULT RADIO MODE
VOICE
0007Z
0006Z
0005Z
0004Z
0003Z
0002Z
0001Z
NO HF LINK
HF LINK ESTABLISHED
HF DATA MODE RADIO FAILED
HF DATA MODE RADIO NORMAL
HF LINK TEST INITIATED
HF LINK TEST - OK
HF LINK TEST - FAIL
TEST
NEW MESSAGES
FLIGHT
INFORMATION
MANAGER
August 14, 2009
