787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Electrical -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
6.10.2 D615Z003-TBC
For additional information, refer to:
• Common Core System
, Ch. 1, Sec. 40
• Modes of Operation
, Ch. 6, Sec. 20
Illuminated (amber) – the BATTERY switch is OFF.
ON – energizes in-flight entertainment and passenger seat systems when sufficient
AC power is available.
OFF – de-energizes in-flight entertainment and passenger seat systems.
Illuminated (amber) – the IFE/PASS SEATS power switch is OFF.
Push – (if AVAIL light illuminated) closes forward external power contactor.
Push – (if ON light illuminated) opens forward external power contactor.
Illuminated (white) – forward external power is selected ON.
(Refer to Modes of Operation
in Chapter 6, Section 20, for additional
information.)
Illuminated (white) –
• forward external power is plugged in and power quality is acceptable
• extinguishes when the ON light illuminates
(Refer to Modes of Operation
in Chapter 6, Section 20, for additional
information.)
ON –
• arms generator control breaker (allows it to close automatically when
power is available)
• closes generator field
OFF –
• opens generator control breaker
• opens generator field
• resets fault protection systems
Illuminated (amber) – the generator control breaker is open.
2
Battery OFF Light
3
IFE/PASS SEATS Power Switch
4
IFE/PASS SEATS OFF Light
5
Forward External Power (FWD EXT PWR) Switches
6
Forward External Power ON Lights
7
Forward External Power AVAIL Lights
8
Generator Control (GEN CTRL) Switches
9
Generator OFF Lights
February 15, 2010
