Closing a circuit breaker
On the ground, perform the following steps:
• select CTRL soft key (displays control menu)
• select CLOSE soft key (closes circuit breaker and closes control menu)
In flight, perform the following steps:
• select CTRL soft key (displays control menu)
• select CLOSE soft key (displays confirmation window)
• select ENTER key on multifunction keypad (closes circuit breaker and
closes confirmation window)
Select CTRL key
Select CLOSE key
Confirmation
window opens
Circuit breaker closes
On Ground In Flight
Select ENTER
key on MFK
DATA CTRL
DATA CTRL
DATA CTRL
SPLY FAN-F/D EQPT
CLG MC
LOW FLOW DET-FWD
EQPT CLG 1 + 3
FAN-MISC CLG MC
CE2127811
CE2127809
CE2127838
21-27 EE COOLING SYSTEM
LOW FLOW DET-FWD
EQPT CLG 1 + 3
CE2127809
CLOSE
CANCEL
LOCK
CANCEL
PUSH KEY ON KEYPAD TO CONFIRM
E
N
T
E
R
LOW FLOW DET-FWD
EQPT CLG 1 + 3
CE2127809
E
N
T
E
R
LOW FLOW DET-FWD
EQPT CLG 1 + 3
CE2127809
DATA CTRL
CBIC DISPLAY
