Flight Controls -
System Description
Copyright © The Boeing Company. See title page for details.
9.20.6 D615Z003-TBC
• roll/bank angle protection
• tail strike protection
Normal Mode
Inputs
Panel
Control
Mode
to generate control surface commands.
Pilot or autopilot control inputs command the PFCs
Surfaces
Control
SPOILERS
RUDDER
FLAPERONS
AILERONS
ELEVATORS
STABILIZER
surface commands
control features
- generate all control
- contain enhanced
- redundant
PFCs
Pilot Control Inputs
control in each axis
Provide redundant
ACEs
ACTUATOR
ELECTRONICS
CONTROL
AUTOPILOTS
COMPUTERS
PRIMARY
FLIGHT
