Displays –
• type of approach, runway, approach front course
• missed approach waypoint name, distance to that waypoint
• source annunciation.
The source annunciation on the third line is completely independent of the
approach data on the first two lines. It identifies the source of navigation
performance for the deviation scales. Possible combinations for source
annunciation are:
Approach reference data appears when the appropriate approach has been selected
to the active route and the airplane is:
• < 150 NM from the missed approach point or
• < 50 NM from Top of Descent or
• FMC is in descent mode
Indicates the navigation path relative to the airplane position.
The pointer:
• indicates the final approach course relative to the airplane position
• unfilled white triangle for FAC if LNAV is engaged
• unfilled magenta triangle for FAC if LNAV is not engaged
• is in view when
• < 25 NM from missed approach point
• airplane position is within 60º of FAC
• filled magenta triangle when captured.
1
Approach Reference and Navigation Source
Horizontal Scale Vertical Scale Scale Source Text
NPS NPS FMC
NPS Glidepath FMC
Final Approach Course Glidepath FMC
ILS Localizer NPS ILS/FMC
ILS Localizer Glidepath ILS/FMC
GLS Localizer NPS GPS/FMC
2
NPS Deviation Pointer
3
Final Approach Course Pointer and Scale
