787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays Chapter 10
System Description Section 20
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.20.1
10.20 Flight Instruments, Displays-System Description
Flight Instruments, Displays20 System DescriptionSystem Description
Introduction
The flight instruments and displays supply information to the flight crew on five
flat panel liquid crystal display units. The units display five primary groups of
information:
• the primary flight display (PFD) with mini-map
• the navigation display (ND)
• the engine indication and crew alerting system (EICAS)
• the auxiliary display (AUX)
• the multifunction display (MFD)
For additional information, refer to:
• Head-Up Display System - Displays
, Ch. 10, Sec. 12
• Head-Up Display System Description
, Ch. 10, Sec. 22
• Primary Flight Displays (PFDs)
, Ch. 10, Sec. 30
• Navigation Displays
, Ch. 10, Sec. 40
• Electronic Checklist Displays
, Ch. 10, Sec. 50
• Electronic Checklist Description
, Ch. 10, Sec. 60
Display Selection and Control
After power-up with the PFD/MFD selectors set to NORM, the displays are in the
default configuration:
• PFDs are displayed on the two outboard display units (DUs)
• a normal-display ND is shown in the left MFD of the Captain inboard DU
• a full-display ND is shown on the First Officer inboard DU
• EICAS is displayed in the right MFD window of the Captain inboard DU
• the CDU is displayed in each MFD window of the lower DU
During normal operations, the displays are typically configured as follows:
• PFDs are displayed on the two outboard DUs
• EICAS is displayed in either the right MFD window of the Captain inboard
DU or in the left MFD window of the First Officer inboard DU
• a normal-display ND is shown in the MFD window on the same inboard
DU as EICAS
• a full-display ND (two MFD windows) is shown on the inboard DU
without EICAS
• the CDU is displayed in each MFD window of the lower DU
February 15, 2010
