168 en | Appendix Control Panels
2016.06 | 08 | F.01U.303.996 Installation and System Reference Guide Bosch Security Systems, Inc.
22 Appendix
This appendix contains information on module address settings, and on reporting.
22.1 Address settings
This section includes address and switch settings for compatible modules.
22.1.1 B208 address settings
Octo-input module number Corresponding point numbers
01, 02, 03, 04, 05, 06, 07, 08, 09 11 - 18, 21 - 28, 31 - 38, 41 - 48, 51 - 58, 61 -
68, 71 - 78, 81 - 88, 91-98
10*, 11*, 12*, 13*, 14*, 15*, 16*, 17*, 18*, 19* 101 - 108, 111 - 118, 121 - 128, 131 - 138,
141 - 148, 151 - 158, 161 - 168, 171 - 178,
181 - 188, 191 - 198
20*, 21*, 22*, 23*, 24*, 25*, 26*, 27*, 28*, 29* 201 - 208, 211 - 218, 221 - 228, 231 - 238,
241 - 248, 251 - 258, 261 - 268, 271 - 278,
281 - 288, 291 - 298
30*, 31*, 32*, 33*, 34*, 35*, 36*, 37*, 38*, 39* 301 - 308, 311 - 318, 321 - 328, 331 - 338,
341 - 348, 351 - 358, 361 - 368, 371 - 378,
381 - 388, 391 - 398
40*, 41*, 42*, 43*, 44*, 45*, 46*, 47*, 48*, 49* 401 - 408, 411 - 418, 421 - 428, 431 - 438,
441 - 448, 451 - 458, 461 - 468, 471 - 478,
481 - 488, 491 - 498
50*, 51*, 52*, 53*, 54*, 55*, 56*, 57*, 58*, 59* 501 - 508, 511 - 518, 521 - 528, 531 - 538,
541 - 548, 551 - 558, 561 - 568, 571 - 578,
581 - 588 , 591 - 598
*Supported by the B9512G only.
Tab.22.16: Octo-input module corresponding point numbers
22.1.2 B299 address settings
POPEX module number Corresponding point numbers
0 9 – 99
1* 100 – 199
2* 200 – 299
3* 300 – 399
4* 400 - 499
5* 500 - 599
*Supported by the B9512G only.
