2016.06 | 08 | F.01U.303.996 Installation and System Reference Guide Bosch Security Systems, Inc.
Address Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6
18 OFF ON OFF OFF ON OFF
19 ON ON OFF OFF ON OFF
20 OFF OFF ON OFF ON OFF
21 ON OFF ON OFF ON OFF
22 OFF ON ON OFF ON OFF
23 ON ON ON OFF ON OFF
24 OFF OFF OFF ON ON OFF
25 ON OFF OFF ON ON OFF
26 ON OFF ON ON OFF
27 ON ON OFF ON ON OFF
28 OFF OFF ON ON ON OFF
29 ON OFF ON ON ON OFF
30 OFF ON ON ON ON OFF
31 ON ON ON ON ON OFF
32 OFF OFF OFF OFF OFF ON
22.1.8 D9210C address settings
Fail mode Central station
Modem4
SDI address setting Keypad display
UNLOCKED SDI #33 81 Door #1
UNLOCKED SDI #34 82 Door #2
UNLOCKED SDI #35 83 Door #3
UNLOCKED SDI #36 84 Door #4
UNLOCKED SDI #37 85 Door #5
UNLOCKED SDI #38 86 Door #6
UNLOCKED SDI #39 87 Door #7
UNLOCKED SDI #40 88 Door #8
LOCKED SDI #33 91 Door #1
LOCKED SDI #34 92 Door #2
LOCKED SDI #35 93 Door #3
LOCKED SDI #36 94 Door #4
LOCKED SDI #37 95 Door #5
LOCKED SDI #38 96 Door #6
LOCKED SDI #39 97 Door #7
