Panel Controller All functions at a glance | en 13
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
– Isolate or de-isolate an element
3.3 Diagnostics
Diagnostics -> Element details Modules
Hardware Panel passport
LED test on modules History log
Network services VAS
Element details
– All info for one element: Display all diagnostic information about an element on a loop of
an LSN module.
– Info for element group: Select and display specific pieces of diagnostic information
about several elements in the selected LSN module.
– Info for all elements on the module: Select and display specific pieces of diagnostic
information about all LSN elements of the selected LSN module.
Modules
– Module passport: Display diagnostic information for each individual module: production
data, software version, CAN ID, compatibility.
– Module Compatibility: Display the software version of the selected module in
comparison with the control panel software version.
– Module status: Display hardware diagnostic data for the selected module.
Only for LSN modules:
– Module status and counters
– Reset counters: Reset the counters that record the frequency with which various events
occur.
Hardware
– Address cards: Additional display for each card slot of the serial number and number of
addresses per card.
– Display
– LED test: Test all LED displays on the panel controller. These remain lit for the
duration of approx. five seconds.
– Key test: Test the operativeness of the membrane keypad.
– Display test: Test the operativeness of the display.
– Display touch test: Test the operativeness of the touch-sensitive surface.
– Adjust touch screen: Adjust the location precision when touching the touchscreen.
– Serial interface: Display statistical data for the transmission.
– CAN bus: Display status of CAN interfaces.
Panel passport
Display diagnostic information such as manufacturing data or software version of the panel
controller.
LED test on modules
Test LED displays of individual modules and simultaneously test all LED displays.
History log
See Maintenance – History log
Network services
– Routing table
