56 en | Bypass Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
12 Bypass
This chapter contains information about the following points:
– Bypassing and un-bypassing elements, page 56
– Displaying and un-bypassing bypassed element groups, page 57
– Displaying list of all bypassed elements, page 57
– Bypassing/Un-bypassing buzzer, page 58
Warning!
Bypassed detectors: Alarm messages from bypassed detectors are no longer displayed, only
faults.
Isolated detectors: Isolated detectors are not analyzed.
12.1 Menu overview
Bypass
Block
-> Bypass -> Show bypassed
devices
Select by
number
Bypass buzzer Printer
Block NAC Transmission
device
HVAC Doorholder
Detector Logical zone Extinguishing
system
Annunciator
Bypass group More... -> Control
element
Interface
module
12.2 Bypassing and un-bypassing elements
Select the element you require in the submenu.
Notice!
Partly bypassed elements, such as loops or bypass groups, can be displayed and completely
bypassed; see Displaying and un-bypassing bypassed element groups, page 57.
Notice!
The menu structure may be different depending on the configuration in FSP-5000-RPS.
Example:
To bypass a detector, select the following in the start menu:
1. Bypass Block
2. Bypass
3. Detector
Various sorting criteria are displayed. See also Working with lists, page 26.
4. Select a selection criterion, e.g. By description.
A list of the detectors is displayed. Refer to Scrolling through lists, page 27 for information
on how to scroll forward and backward through the list.
5. Select the required list fields.
The list fields are marked.
