Panel Controller Fault message | en 53
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
11.2.4 The newest message
The newest message is displayed at the end of the list.
Notice!
15–30 seconds after the last entry (e.g. after scrolling through the list), the first and oldest
fault message is displayed at the beginning of the list again.
11.2.5 Displaying individual elements of an element group
To display the individual elements in an element group, select the element group you require.
The fault messages of the individual elements are listed.
11.2.6 Information about individual elements
The trouble message contains information about:
– Element category
– Message type
– Element address
– Message number
– Additional information (e.g. the installation location)
Example:
Fault Transmission device 00026- 004
#002 Cafeteria
Element category: Transmission device
Message type: Fault
Element address The following transmission device has caused a fault:
00026 - 004: The fourth transmission device (004) in the 26th
group (00026).
Message number The fault messages are numbered chronologically.
The message number in the second line indicates the sequence
in which the fault messages were received.
002: The second fault message to be received.
Installation location of the
element
Cafeteria
Notice!
Depending on the configuration of the system, either the logical or physical address of the
element is displayed.
To display more information about an alarm message, see Displaying additional information,
page 53.
11.2.7 Displaying additional information
To display further information about the individual elements, select the fault message you
require.
