Panel Controller Diagnostics | en 65
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
1. In the start menu, select Diagnostics
2. Network services
3. Routing table
A table with routing information is displayed.
All networked nodes that can be reached via the node currently being operated and that are
recognized within the system network are displayed under Node.
CAN1 to USB1 designate the interfaces on the currently operated panel node. In this example,
it is the node 1 interfaces.
The type of interface on the panel node currently being operated is listed under interface.
The following interfaces can be designated:
– CAN 1 interface
– CAN 2 interface
– Ethernet 1 (IP multicast or UDP tunnel)
– Ethernet 2 (IP multicast or UDP tunnel)
– Serial Interface
– USB 1 interface
The number of nodes that need to be passed in order to reach the listed node is entered
under distance. For nodes that are directly reachable via IP multicast, the value is 1; for nodes
that are connected via other interfaces (e.g. CAN) to nodes reachable via IP multicast, the
value is increased in increments accordingly (e.g. connected via IP multicast + CAN1/CAN2,
value = 2).
A node number from 1 to 64 can be assigned to panels. All numbers above 240 (241-255) are
assigned dynamically and used, for instance, for an OPC server or a PC with FSP-5000-RPS
software.
14.7.2 Consistency check
Inconsistencies between the network settings configured in FSP-5000-RPS and those set in
the panel controller are displayed under Diagnostics - Network services -
Consistency check.
1. In the start menu, select Diagnostics
2. Network services
3. Consistency check
Where inconsistencies are identifiable between the network settings saved in the panel
controller and those configured in FSP-5000-RPS, these are indicated. You can use the
arrow key on the display to alternate between displaying Problems of active
configuration and Problems expected after restart.
Problems of active configuration
The table indicates inconsistencies between the network settings of the panel controller's
active configuration ("active") and the settings configured in RPS ("configured").
Problems expected after restart
The table indicates inconsistencies between the network settings that have already been
configured on the panel but which do not take effect until restart ("saved") and the settings
configured in RPS ("configured").
14.7.3 Ethernet ports
To display a table listing the various parameters and the status of the two Ethernet ports:
1. In the start menu, select Diagnostics
2. Network services
