Panel Controller Alarm | en 43
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
If more than four alarm messages have been received, scroll through the list in order to display
the next messages (see Scrolling through lists, page 27).
Notice!
The latest message is always displayed at the end of the list.
Display during an alarm
The buttons located beneath the alarm message on the display can be used to initiate the
corresponding actions:
Acknowledge Signals off Signals on Reset
– Acknowledge: Touch this button to acknowledge all of the alarm messages shown on the
display; see also Acknowledging a message, page 46.
– Signals off: Touch this button to switch off activated external notification appliances; see
also Switching external signaling devices on and off, page 47.
– Signals on: Touch this button to switch on deactivated external notification appliances;
see also Switching external signaling devices on and off, page 47.
– Reset: Touch this button to reset all of the alarm messages shown on the display; see
also Resetting alarm message, page 49.
9.4.3 Sequence of the alarm messages
The messages are displayed in chronological order.
– The newest alarm message of a logical zone is always displayed at the end of the list.
– The first and oldest alarm message of a logical zone is displayed at the beginning of the
list. The next three messages are displayed as you scroll through the list.
Notice!
30 seconds after the last entry (e.g. after scrolling through the list), the first and oldest alarm
is displayed at the beginning of the list again.
9.4.4 Information about logical zones in the alarm state
The alarm message contains information about:
– The element category
– The message type
– The address of the detector group
– The number of detectors that have triggered an alarm in the respective logical zone
– The message number
– Depending on the configuration, additional information such as the installation location
Example:
Fire Zone 00005
#001 Office 1 (6)
Message type
The message type Fire is reported.
Depending on the configuration, the message type may be defined more specifically, e.g. Fire
PAS for a fire alarm with alarm verification.
Address of logical zone
00005: the fifth logical zone triggered the first fire alarm.
