Panel Controller Remote keypad | en 39
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
8 Remote keypad
In the FSP-5000-RPS programming software, the address of a panel to which a connection is
automatically made from the remote keypad can be entered in the dialog regarding the node
of the remote keypad. In addition, further panels with which a connection can be made can
also be assigned.
It is not possible to log out of the automatically assigned connection. A connection can be
established with other panels without any further queries.
8.1 Operation and display
The prerequisite for operating a remote keypad is that an operator with an access
authorization > 1 is logged in. If an operator with access authorization = 1 is logged in, no
LEDs are activated and no messages displayed. If no operator is logged in, only the standby
screen is displayed.
Notice!
It is possible to specify in the FSP-5000-RPS programming software that messages are to be
displayed on the remote keypad, even if no operator is logged in. In this case the operation of
all functions is possible with permission level =1.
If the remote keypad is not connected to a panel, the following symbol is displayed on the
standby display and in the status bar:
Notice!
In the FSP-5000-RPS programming software, a time span can be specified after which an
operator who is logged in to the panel controller is logged out.
The following functions cannot be executed from the remote keypad via a remote connection:
– LED, foil, display and display touch test
– Adjust touch screen
