Panel Controller Diagnostics | en 61
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
14 Diagnostics
This chapter contains information about the following points:
Element details, page 61: Diagnostic information about an LSN module and about
elements of a selected LSN module
Modules, page 62: Diagnostic information (software version) and hardware diagnostic
data about modules
Hardware, page 62 Information about released addresses, statistical data for the
transmission, and the execution of display tests
Panel Passport, page 64 Diagnostic information about the panel controller
LED Test on modules, page 64 Testing the LED display of modules
History log; see Maintenance – history log, page 77
Network services, page 64 Information on the availability of other nodes within the
system network
Voice alarm systems, page 68
Diagnostic information about a connected voice alarm system (VAS)
14.1 Menu overview
Diagnostics -> Element details Modules
Hardware Panel passport
LED test on modules History log
Network services VAS
14.2 Element details
To display diagnostic information about the elements in a particular module:
1. In the start menu, select Diagnostics
2. Element details
A list of the LSN modules is displayed.
Notice!
The numbers before the module names indicate the slot of the module on the panel.
1. Select the list field you require.
On the display, various possibilities for selection are offered:
2. Select:
All info for one element to display all diagnostic information about an element on
one loop of an LSN module.
Info for element group to display particular diagnostic information about several
elements of the selected LSN module.
Info for all elements on the module to display particular diagnostic information
about all LSN elements of the selected LSN module.
The subsequent procedure for all three selection possibilities will be presented by means
of an example. The other two possibilities deviate only slightly from this.
Example:
1. Select Info for element group.
A list of the elements of the selected LSN module is displayed.
