Panel Controller Maintenance – history log | en 77
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
17 Maintenance – history log
In the history log, all data about particular events or device types is stored sorted by date and
time. To display only particular data, filters can be set.
In addition to a menu overview, this chapter contains information about the following points:
– Selecting filters, page 77
– Setting filters, page 77
– Change Filter, page 78
– Combining several filters, page 78
– Status bar functions, page 78
– Printing out data, page 79
17.1 Selecting filters
The following filters are available:
Filter Data, filtered by...
Without filter All data
Show all Delete filter Display all data with specification of event number, date,
time, element number and message type. Existing filters are
deleted.
Period Starting date, end date and time
Event types Message types, such as Fault
Device types Device types, such as Detectors
Address range Address range within a system
User commands Selected function fields, such as Acknowledge or Reset.
Walktest Elements switched to walktest mode
If one or more filters have been set, the Change filter field in the status bar is highlighted in a
dark color.
17.2 Setting filters
To display only particular data, a filter can be set.
Example:
To display only data that was stored in connection with a particular event, such as Fault:
1. In the start menu, select Maintenance
2. History log
3. Select the Event types filter.
A list of all event types is displayed.
4. Select a list field, e.g. Fault.
In the status bar, the Change filter field has a black background. See also Change Filter,
page 78.
5. Select Show in history log.
A list of all fault messages is displayed. The events are sorted in ascending order by date
and time.
The fault messages are numbered chronologically. The leading number indicates the
sequence in which the fault messages were received.
