Bosch FSA 760 - 1 Symbols Used; In the Documentation; Warning Notices - Structure and Meaning; Symbols in this Documentation

| 1 689 989 298 2017-03-08 Robert Bosch GmbH
18 | FSA 760 Edition | Symbols used
1. Symbols used
1.1 In the documentation
1.1.1 Warning notices -
Structure and meaning
Warning notices warn of dangers to the user or
people in the vicinity. Warning notices also indicate
the consequences of the hazard as well as preventive
action. Warning notices have the following structure:
Warning
symbol
KEY WORD – Nature and source of hazard!
Consequences of hazard in the event of
failure to observe action and information
given.
¶ Hazard prevention action and information.
The key word indicates the likelihood of occurrence
and the severity of the hazard in the event of non‑
observance:
Key word Probability of
occurrence
Severity of danger if
instructions not observed
DANGER Immediate impending
danger
Death or severe injury
WARNING Possible impending
danger
Death or severe injury
CAUTION Possible dangerous
situation
Minor injury
1.1.2 Symbols in this documentation
Symbol Designation Explanation
!
Attention Warns about possible property damage.
i
Information Practical hints and other
useful information.
1.
2.
Multi‑step
operation
Instruction consisting of several steps.
e
One‑step
operation
Instruction consisting of one step.

Intermediate
result
An instruction produces a visible
intermediate result.
"
Final result There is a visible final result on
completion of the instruction.
1.2 On the product
! Observe all warning notices on products and ensure
they remain legible.
Comply with these operating instructions
and all technical documentation relating to
the FSA 760 Edition and the components
used!
Caution
1. Switch the ignition off.
2. Connect FSA 760 Edition to the battery (B–) or
engine ground.
3. Switch the ignition on.
Caution
1. Switch the ignition off.
2. Disconnect FSA 760 Edition from the battery (B–) or
engine ground.
Disposal
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
Pull or push the FSA 760 Edition only by
means of the trolley handles.
