Bosch Solution 16plus Installation Manual

6-3
Bosch Security Systems 05/10 BLCC100I
Solution 16
plus
 Installation Manual  Area Programming
2) Use the up and down arrow keys to select the required chime
mode. If the chosen type requires a time parameter use the
right arrow to move to the time eld and then use the up and
down arrow key to select the appropriate time. When nished
press [OK].
Chime Mode A001
Chime For 000 Seconds
Press  OK to SAVE
ARE A P ROP E RT IES
Areas > Area Properties >
Area Name

-

MENU 2-1-0
A r e a 1 N a m e
This menu allows you to program the name for each area. Each
area name can be programmed with up to 16 characters. At
factory default, only Area 1 is used. The Solution control panel
can have a maximum of 8 independent areas programmed.
1) Enter [MENU] + [2] + [1] + [0] and select the area from the list
and press [OK].
Area Name A001
Security System
Press  OK to SAVE
2) Use the arrow and number keys to move and change text.
When the Area Name is complete, press [OK]. At any time you
can press the [OFF] key to clear the text from the current cursor
position to the end of the line.
i
Note
See Alpha Text section in Section 4 - Programming Overview for
further detail on entering alpha text.
Areas > Properties >
General Options

MENU 2-1-1
1 Exit Time Restart N
2 Reset Alarm Memory On Disarm N
3 Duress Allowed Y
4 Acknowledge All Faults N
5 Single Button Arming - All On Y
6 Single Button Arming - Part On Y
7 Link To Common Area Y
8 Single Button Part Off N
The above options are programmable per area.
1) Enter [MENU] + [2] + [1] + [1] and select the area from the list
then press [OK].
2) Use the up and down arrow keys to highlight the option then
press the [ON] key to enable or the [OFF] key to disable.
Exit Time Restart
Reset Alarm Memory
 Duress Allowed
Press
 OK ON OFF MENU
3) Repeat Step 2 until all options are programmed as required,
then press [OK] to save and exit or press [MENU] to exit
without saving.
Exit Time Restart
The exit delay timer will restart (once per arming cycle) when the
same entry/exit delay zone is faulted a second time during exit delay
(eg. If an entry/exit delay zone is unsealled, restored and unsealled a
second time during exit delay = exit time restart).
Reset Alarm Memory On Disarm
Clears all alarm memories displayed on the keypad when a user
has turned the corresponding area o. If this option is not set,
alarm memory will continue to display until the user has turned the
corresponding area ‘on’ again.
Duress Allowed
If a user is being forced to turn o the security system under duress
they can disarm the system and initiate a silent duress alarm.
To trigger the duress alarm enter your PIN then repeat the last two
digits of your PIN before pressing [ON], [OFF], or [OK] key.
Example:
If your PIN is 2580, to send a duress report when the area is o,
Enter, [2] + [5] + [8] + [0] + [8] + [0] + [OK] or [ON].
If your PIN is 2580, to send a duress report when the area is on,
Enter, [2] + [5] + [8] + [0] + [8] + [0] + [OFF].
i
Note
Software Version 1.02 or higher has been corrected to now send
‘Duress’ reports in SIA format.
Acknowledge All Faults
If this option has been programmed, the control panel will force a
user to acknowledge each trouble condition even though the trouble
condition has already cleared.
If this option is not programmed, any trouble condition that occurs
will not have to be acknowledged if it has already been rectied or
cleared.
Single Button Arming Allowed – All On
This option allows users to simply press the ON key to turn the area
ON. All zones being armed must be sealled. If open and close reports
are programmed, the user ID number will report as 000.
Single Button Arming Allowed – Part On
This option allows users to simply press the Part On key to turn the
area Part On. All zones in the being armed must be sealled. If open
and close reports in Part Mode are programmed, the user ID number
will report as 000.
Link To Common Area
This option causes the selected area or areas to control the common
area. If this option is not selected for an area then it will be able to
operate independant of the common area. See MENU 7-7-1 — Area
Options to enable the common area.
