Bosch Security Systems 05/10 BLCC100I
Solution 16
plus
Installation Manual Device Programming
Type = Keyfob
Ur001 User 1 Name!
RFID = 123456789
Press OK or MENU
3) To test another transmitter, repeat step 2. A beep will be heard
each time a new RFID is received and the new number will be
displayed.
SER IAL DE VIC E O PT I ON S
Devices > Serial Device >
Device Type
MENU 6-3-0
0 = Disabled 0
1 = Serial Printer
2 = Computer
This menu sets the type of serial device that the panel will be
connected to.
1) Press [MENU] + [6] + [3] + [0]. The keypad will display the
current device type.
Device Type P001
00 - Diabled
Press 0-9 OK to SAVE
2) Use the up and down arrow keys to select the Device Type
required then press [OK] to save and exit or press [MENU] to
exit without saving.
Devices > Serial Device >
Baud Rate
MENU 6-3-1
0 = No Device Connected 0
1 = 300 Baud 5 = 9600 Baud
2 = 600 Baud 6 = 19200 Baud
3 = 1200 Baud
4 = 2400 Baud
This menu sets the baud rate or speed that the panel will send
data to the serial device. This should be set to the same baud
rate as the serial device.
1) Press [MENU] + [6] + [3] + [1]. The keypad will display the
current baud rate.
Baud Rate P001
00 - No Device Conn
Press 0-9 OK to SAVE
2) Use the up and down arrow keys to select the Baud Rate
required then press [OK] to save and exit or press [MENU] to
exit without saving.
Devices > Serial Device >
Flow Control
MENU 6-3-2
0 = No Handshaking 0
1 = Hardware
2 = Xon-Xoff
This menu sets the appropriate ow control for the device you
are connecting the serial board to. The ow control method
must be the same on both devices for a serial connection to be
established.
1) Press [MENU] + [6] + [3] + [2]. The keypad will display the
current ow control setting.
Flow Control P001
00 - No Handshaking
Press 0-9 OK to SAVE
2) Use the up and down arrow keys to select the Flow Control
required then press [OK] to save and exit or press [MENU] to
exit without saving.
Devices > GSM Modem >
Report Format
MENU 6-5-0
0 = SIA 0
1 = CID
2 = Domestic
Reserved for future use
Devices > GSM Modem >
Options
MENU 6-5-1
0 = Reserved 0
1 = Reserved
2 = Reserved
Reserved for future use.
» » E N D O F S E C T I O N « «
