12.2 Standard Shipping List
Pre-Installation Shipment
Description Dimension (mm) Weight (kg) Crates
Floor box 12” 1200 x 800 x 450 60 1
Floor box 17” 1000 x 800 x 580 85 2
On-floor box 1200 x 800 x 650 50 1
Main Installation Shipment
Description Dimension (mm) Weight (kg) Crates
Basic computer system 950 x 880 x 1930 286 1
Medical hardware 1200 x 800 x 1200 150 1
Medical hardware 1200 x 800 x 1200 110 1
Dual X-ray generator 1750 x 680 x 1020 250 2
X-ray tubes, pre-transformer and
cabling
1750 x 680 x 1020 245 1
Imaging couch top 2050 x 800 x 580 40 1
ET Robotics 1050 x 900 x 380 75 1
The X-ray tubes must be handled with care. Transport and store them always upwards
(vertically) to protect the glass bulb from cracking through mechanical shock. A
void
mechanical shocks in general.
Standard Shipping List
106 Site Planning Manual Rev. 1.0
ExacTrac Ver. 6.x
