7.3 System Mains Power & Protective Earth Cabling
General Information
The mains power/protective earth (PE) cabling material within the ExacTrac system (supplied by
Brainlab) complies with worldwide harmonized certification “HAR” and dedicated certifications for
the North American/Canadian market.
In cases where the provided certifications are not suf
ficient for installation (e.g., regional
regulatory or local installation aspects), the customer is responsible for providing adequate cabling
material. In this case, refer to the table below for the necessary technical specifications of
Brainlab’s cable material:
NOTE: Not all Brainlab provided cables material is plenum rated.
NOTE: Label the ExacTrac phase input uniquely to avoid misinterpretation among products.
Description Mandatory specs General Specs Approvals
Mains power cable
(60 m)
•
3 x 2.5 mm
2
(3 x 14AWG)
•
Cable Ø range min- max: 4 -
10 mm
• U
N
> 250VAC
• Conductor colors: Black/
white, overprint; green/
yellow
•
Cable sheath color: Gray
• Cable Ø: 9.6 mm
• U
test
= 3000VAC
• H05VV5-F HAR, HD21.13
•
CSA-A
WM I A/B II A/B
Protective Earth (PE)
cable (70 m)
•
1 x 16 mm
2
(1x 6AWG)
•
Cable Ø range min-max: 4
-10 mm
• U
N
> 250VAC
• Conductor color:
•
Green/yellow
•
Cable Ø: 8.9 mm
• U
test
= 3000VAC
• UL Style 1063 MTW, UL rec.
•
A
WM-Style 1015
• CSA: TEW
• (VDE 0281/HD 21)
Protective Earth (PE)
cable (50 m)
•
1 x 2.5 mm
2
(1x 14A
WG)
• Cable Ø range min-max: 3.5
-10 mm
• U
N
> 250VAC
• Conductor color:
•
Green/yellow
•
Cable Ø: 3.7 mm
• U
test
= 3000VAC
• UL Style 1063 MTW, UL rec.
•
A
WM-Style 1015
• CSA: TEW
• HAR: H07V-K, X07V-K
• (VDE 0281/HD 21)
Cabling Plan
You must install mains power and PE cables between the computer cabinet and power distribution
boxes, as well as PE cables between each system component to the PE bar (grounding spot)
according to table 1 ExacTrac cables (beside cables for system interlocks).
Cable #
Cable Type Destination Start Destination End Wire Cross-
Section
Cable Ø
with Copper
32 Mains power Computer cabinet (1.0)
In-room distribution
box (1.3)
3 x 2.5 mm²
(14AWG)
9.6 mm
33
Mains power Computer cabinet (1.0)
Control room distri-
bution box (1.5)
3 x 2.5 mm²
(14AWG)
9.6 mm
35
PE Computer cabinet (1.0)
In-room distribution
box (1.3)
16 mm
2
(6AWG)
8.9 mm
36
PE Computer cabinet (1.0)
Control room distri-
bution box (1.5)
16 mm
2
(6AWG)
8.9 mm
34
PE Computer cabinet (1.0)
PE bar (treatment
room)
16 mm
2
(6AWG)
8.9 mm
-
PE
In-room distribution box (1.5)
see comment 2 (Figure 36)
PE bar (treatment
room)
16 mm
2
(6AWG)
8.9 mm
ELECTRICAL REQUIREMENTS
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x 77
