4.2.2 External Dimensions of the On Floor Boxes
Side View
306mm
Figure 15
Top V
iew
902mm
840mm
Figure 16
On Floor Boxes (Optional)
44 Site Planning Manual Rev. 1.0
ExacTrac Ver. 6.x
