Brainlab ExacTrac - Treatment Room Overview

3.1.2 Treatment Room Overview
Sample Set-Up
All major ExacTrac components and positions within the bunker have a dedicated numbered label
for further reference.
The following image shows an overview of the main system components in a treatment room
(diagram not meant to scale):
Floor Box with
X-Ray Tube
(left side)
2.1a
IR and Video
Camera System
1.1
Flat Panel
Detector
(right side)
X-Ray
Warning Light
Control-Room Workplace
X-Ray
Warning Light
Control Room
Distribution Box
Wall Mounted
Touch Screen
Monitor
(standard)
Ceiling Mounted
Touch Screen
Monitor
(optional)
Network Plug
(provided by
Hospital)
1.2
2.3a
2.5b
Treatment Couch
0.1
Primary Beam
Lasers
1.2
1.5
2.5a
Isocenter
2.4
ExacTrac Console
1.0
Computer Cabinet
Stand & Gantry
0.0
In-Room
Distribution Box
1.3
X-Ray
Dual Generator
2.0a 2.0b
4.0
2.2a
Floor Box with
X-Ray Tube
(right side)
2.1b 2.2b
Flat Panel
Detector
(left side)
2.3b
Control-Room
Workspace
1.6
Emergency Off
Emergency Off
Emergency Off
max. radius 2900
EXACT couchtop
with foot extension
3.2
External
Bluetooth Module
Power Plug
(for Robotics
Charger)
L
LL
15°
Figure 1
Treatment Room
16 Site Planning Manual Rev
. 1.0
ExacTrac Ver. 6.x
